QO-100: Satellite Receiving Technology. And Explanation Of A PLL

9FM5HLqIRjk/default.jpg

When we started our bonus project to communicate via the geostationary satellite QO-100, we created a to-do list:
- A high power 2.4GHz transmitter
- A sensitive receiver for 10GHz
- And an internet connection to the Adalm Pluto
In the last video, we built a prototype for the transmitter. We just need an antenna to complete the task. So this week, we will make a cheap first version of the receiver. And hopefully, listen to the first signals from space. And you will learn "PLL."

In this video, we will:
- Find out how we can receive such highest frequency signals for only a few dollars
- We will learn how to reduce frequencies and why this is good for our wallet
- We will learn how stable highest frequencies are created
- We will see the advantages of mass production
- And we will try to get a signal from space
